An introduction to Prism Audio DSCOPE M1 Audio Analyzer

M1 Audio Analyzer Free Plugin Download

The Prism Sound/Spectral Measurement dScope Series III software platform is consistent with the dScope M1 interface family. The M1 hardware is supplemented with a variety of software versions that can be bought to permit feature choices and various hardware variants. Analog Generator output values up to +26dBu are supported. The Analog inputs with a sampling rate of up to 768kHz and a bandwidth of more than 300kHz are supported. There are two-channel digital Input and output(AES3 and S/PDIf modes).The streaming design offers for more flexibility in creation and analysis, as well as faster processing. The most basic electro mechanical components are used for lengthy service life. 12V AC-DC power converter Small size: 36x230x180mm, rack-mount ears available.

All standard audio tests and more with easy computerization and reportage in a compact and lightweight package
You can use the software with ease

Simple "Auto Sequence" "code-free" automation based on your previous configurations or write your own automation in VBs, Python, C++/C#, or another language. The Bandwidth from DC to >200kHz; 100V RMS maximum input; THD+N residual typical -110dB

There is an automation option with +48 phantom power, and it also provides the excellent feature like any other professional equipment

The Tetrahedral Test Chambers and bespoke products that can completely surround a speaker cabinet or Head and Torso Simulator (HATS) and create balloon responses and 2*Pi measurements are available from Hill Acoustics Loudspeaker Test Chambers. These eliminate the need for costly anechoic chambers and give a precise positioning jig that ensures very reproducible results.

Features of the dScope M1

• The Analog Input and output (48kHz/96kHz/192kHz)

• The Digital Input or output is set to a maximum of 192kHz

• The Sound Card I/O uses ASIO/WDM devices

• The other supported devices are Bluetooth, Dante, and MADI

• The Amplitude, Frequency, and Phaseanalyses the signal

• Sine, White/Pink noise, Swept sine, Twin-tone generated the signal

• Basic AES3 is the status of the channel.

• Measurements of time and frequency domain.

• THD+N, THD, individual/odd/even harmonics, IMD (CCIF / SMPTE-DIN)

• Cross-talk, Balance, Gain, Noise

• Standard and user weighting filters

• There is FFT Analysis with Smart FFT Detectors.

• The Sweeps are another unique feature.

• An impulse Response Test can be done.

• Scripting

• Code freeThe test automation of code is free, and the reports can be generated using Excel, PDF, or HTML.

• The External control is done through ActiveX like C++, Python, LabView, Matlab, etc.

From designing the product through production line QC testing, Prism Sound's audio test solutions are appropriate for automotive test applications. All components of the In-Car Entertainment (ICE) system may be examined with a single instrument.

You may use the audio devices to send test signals straight from dScope III to your PC's Bluetooth chipset or the EUT's USB dongle. It would be best to connect directly between the test system and Bluetooth device for your Bluetooth system tests. This will give instant way into the distinctive Scope III feature set, which includes sweeps, regulation, Smart FFT detectors, live measurement traces, multi-tone analysis, automation for QC applications. The most significant benefit of adopting dScope Series III for Bluetooth testing is that it eliminates the requirement for tedious wave file generation and processing in external software.

Finding audio faults in a broadcast chain is more difficult today than it has ever been. For analog signal chains, the tried and true approaches no longer apply. With this in mind, the dScope and DSA-1 were created in collaboration with significant broadcasters and their standards bodies. They have measuring capabilities that are not available on any other equipment. Built-in automatic analysis tools, such as a watchdog event recorder for detecting and catching those pesky clicks and pops, as well as ways to look at and analyze the digital stream, give capabilities that no other instrument can match.

Prism Sound's dScope Series III audio test system is known as the world's first electronic and acoustic test system which can address the Windows® audio devices. The dScope Series III combines both software and hardware analysis systems that analyze Windows Sound devices as if they were any other input or output (WDM or ASIO). It may either direct to a sound card or is measured by using a sound card as input, and it would do cross-domain, analog or digital, input or output.

Prism Sound provides comprehensive system models and examination capabilities for electro-acoustic transducer design. The LOUDSOFT software modeling suite allows engineers to build and simulate a full loudspeaker from the motor and soft components of the transducer using the inclusion and cross-over design. The dScope Series III Audio Analyzer is the only instrument in the world that can assess a complete electro-acoustic system, including loudspeakers, microphones, integrated analog and digital amplifiers, A/D, and D/A converters, and a Windows® audio communication link that includes USB and Bluetooth.

Prism Sound delivers audio measuring solutions for the whole range of consumer audio and home entertainment goods, which is ever-diversifying. The product design right through to the production line, the dScope Series III test and measurement platform deliver inclusive test routines from media players to Bluetooth speakers, from portable FM and digital radios to reference-quality home cinema schemes, from noise-stopping headphones to mobile telephones.

For production line / QC testing applications, the dScope Series III is one of the fastest and most capable audio test options. With the ability to concurrently measure over 100 audio parameters and sophisticated FFT-based analysis features like multi-tone testing and impulse response analysis, the dScope Series III may help you enhance throughput and verify that you're shipping fault-free goods.

The dScope Series III Audio Analyzer has unrivaled capabilities for evaluating mobile audio devices such as MP3/Media players, earbuds, and headphones. Measurements can be taken in accordance with industry standards, such as the British Standard BS EN 50332 for the hearing safety of portable music players. Furthermore, up to 40+ performance metrics, such as warp, sound, frequency response, gain, signal-to-noise, ratios of odd to even harmonics, and dynamic range, can be measured and analyzed in real-time using the analyzer's real-time interactive measurements and unique Smart FFT™ capability. The dScope analyzer can readily adjust for the ear's frequency response characteristics when using ear simulators, assuring reliable measurement results of earbuds and headphones.

Although the dScope Series III audio analyzer is a soft instrument, it may be utilized to obtain those difficult-to-obtain findings. Automation may be used to simplify complicated processes and make the impossible feasible in several ways. The user-defined FFT detector may be designed to yield a result that can be utilized just like any other FFT detector result: swept, limit tested, used in regulatory algorithms, and so on.

So, Prism Sound's audio test and measurement solutions were created to help the company design and construct the highest-quality, reference-grade studio recording interfaces. However, they are now utilized worldwide to assist other manufacturers and designers in developing their own products. Engineers can test their goods more thoroughly and quickly than ever before with no other audio test and measurement solution. Engineers can test their products more extensively and promptly using no additional audio testing and measuring solution.

Prism Sound is the industry leader in semiconductor audio measurement and test equipment. You must be able to access the audio at the board level to accomplish this. The VSIO adaptor for the dScope Series III audio analyzer makes it simple to achieve this with digital audio. It's the only multiformat I2C capable multichannel digital serial interface on the market, with 16 channels of audio data on a single wire and a dedicated control connection for I2C or SDI serial transmission. This is excellent for every chip-level audio design need. The VSIO can handle up to 16 multiplexed channels on a single wire, 8 on each of two wires, or four on each of four lines without any additional hardware.
