Prism Audio Atlas Multi-Track Recording Interface

Prism Audio Atlas Multi-Track Recording Interface

In addition to professional musicians, songwriters, engineers, and producers, the Prism Atlas is a USB multi-track audio interface that may be used for personal recording and sound creation. It is also suitable for recording studios, post-production facilities, and score stages. At its core, Atlas is a professional music and sound recording tool used for everything from mixing to overdubbing to stem-based mastering to critical listening applications.

As a dedicated device, Atlas delivers Prism Sound's acclaimed performance, sound quality, and state-of-the-art clock technology in a format compatible with both Windows (Vista, 7 and 8, 32 and 64 bit, ASIO) and Mac OS X 10.4.11 then later (Intel). The Atlas can be programmed to work with a computer, but it may also be used stand-alone by connecting to its ADAT, S/PDIF, or AES3 I/O.

In addition to the Orpheus, the Prism Sound Atlas is a 2U multi-channel 24 bit/192kHz USB audio interface that continues the legacy of high-quality audio interfaces that began with the Prism Sound Atlas.

Features

• No-compromise audio quality with Prism Sound technology.

• A dedicated USB interface is provided.

• MDIO (Multichannel Digital I/O) extension port (multi-channel digital I/O is a type of digital I/O).

• CORE AUDIO is directly compatible with Mac OS X 10.4 and higher.

• Eight premium-quality A/D and DA channels with "Prism Sound" technology

• Eight high-quality integrated microphone preamplifiers (typ.-130dBu EIN)

• Each mic preamps has switchable phantom power and 20dB pads.

• MS Matrix processing applied to microphone inputs

• There are two instrument inputs.

• RIAA Equalization on the first and second inputs

• The use of "Overkillers" on each analog channel of Prism Sound helps control transient overloads.

• Fully-floating (isolated) balanced architecture for the best noise rejection available.

• Mono or stereo input combinations are available.

• The outputs can be switched between the workstation bus and the Atlas mixer.

• A low-latency digital mixer with "console-quality" performance for foldback monitoring.

• Every mixer channel has a fader, a pan knob, a cut knob, and a solo knob.

• Dual headphone outputs, each with its volume control on the front panel

• Front-panel master volume control and mute may be assigned to individual channels.

• The Configurable for stereo, 5.1 or 7.1 surround sound, or a combination of the three.

• Inputs and outputs for S/PDIF have built-in sample rate conversion (SRC).

• Prism Sound 4-curve SNS noise-shaping digital outputs (available as an option).

• Modern clock generation is achieved by using a proprietary hybrid 2-stage DPLL.

Atlas is a USB multi-track audio interface designed for personal recording and sound production, as well as for professional musicians, songwriters, engineers, and producers, as well as recording studios, post-production facilities, and scoring stages. At its core, Atlas is a professional music and sound recording tool used for everything from mixing to overdubbing to stem-based mastering to critical listening applications.

Signal path

As a dedicated device, Atlas delivers Prism Sound's acclaimed performance, sound quality, and state-of-the-art clock technology in a format compatible with both Windows (Vista, 7 and 8, 32 and 64 bit, ASIO) and Mac OS X 10.4.11 then later (Intel). The Atlas can be programmed to work with a computer, but it may also be used stand-alone by connecting to its ADAT, S/PDIF, or AES3 I/O.

Using the audio driver on the host computer, you can connect up to eight analog input channels and up to ten digital input channels to your audio workstation software for recording and mixing. In a similar vein, eight analog output channels, up to ten digital output channels, and stereo headphone outputs can all play up to 20 separate tracks simultaneously. If you want to use the built-in DSP mixer to drive each output pair (1-2, 3-4) or the headphone output with a local mix of any selection of inputs, you can do so through the controller applet. This is useful for low-latency foldback or monitoring to headphones or main outputs. Automatic imbalanced operation is available on all analog inputs, which are electrically balanced. Analog outputs are electronically balanced with 'bootstrapping,' which means the level is maintained even if one of the legs is disconnected.

Uncompromising audio quality, courtesy of Prism Sound

Atlas does not make any concessions when it comes to audio quality. Years of research and development into digital audio conversion, as well as significant consultation with Prism Sound's clients, have culminated in this product.

USB interface that complies with industry standards

Prism Sound has recognized the rising importance of native processing power for professional users. The fact that software programmers for conventional PC and Mac platforms have seen significant improvements in recent years has been considered. Atlas is equipped with a USB2 interface. In addition to being supported natively in Mac, iPod, Linux, and Android, this interface is also supported in Windows through a driver.

MDIO (Multichannel Digital Input and Output)

Atlas and Titan are compatible with Prism Sound's MDIO expansion cards, which enable an alternate "host" connection for the Atlas and Titan. It is typical for the "host" to be a computer. The Atlas or Titan interface establishes a link between the host and the external analog and digital audio I/O ports. It is possible that the host connection would always be used if the MDIO expansion card wasn't installed; however, this is not the case.

In addition to the standard host connection, the MDIO expansion slot provides an alternate host connection. It will not necessarily disable the USB port, but in the case of the Pro Tools interface MDIO-PTHDX, the USB port is turned off when the Pro Tools interface is being utilized, and the USB port is not turned off otherwise. For the time being, only the MDIO-PTHDX expansion card is available for purchase. Others may be developed in the future.

Inputs and outputs that are adaptable

A large number of professional users told us they desired a highly integrated solution with instrument and microphone inputs, line outputs that could be used for stereo or multi-channel monitoring and foldback to performers, and a line output that could be used for stereo or multi-channel monitoring and foldback to performers. As a result, Atlas has a maximum capacity of 18 concurrent input and output channels, as well as stereo headphones, thanks to its eight analog recording channels, eight monitoring outputs, stereo digital input, output on a phono connector, and concurrent optical digital I/O ports that can interface with S/PDIF or ADAT data formats.
